General data

• Balancing:
  Half key
• Color:
  RAL7030
• Direction of rotation:
  left or right
• Frame size:
  100
• Housing type:
  A
• Insulation class utilization:
  B
• Material of housing:
  Aluminium
• Motor type:
  Regular
• Mounting:
  B34a

Electrical data

• Efficiency class OP1:
  IE4
• Efficiency class OP2:
  IE4
• Frequency OP1:
  50
• Pole:
  2
• Power OP1:
  3
• Power OP2:
  3
• Starting current factor OP1:
  9,5
• Starting current factor OP2:
  9,5
• Starting torque factor OP1:
  2
• Starting torque factor OP2:
  2
• Starting torque factor OP3:
  2,2
• Voltage OP1:
  230/400 V
• Voltage OP2:
  265/460 V

Mechanical data

• Speed OP1:
  2930
• Speed OP2:
  3516
• Speed OP3:
  3516
• Torque OP1:
  9,78
• Torque OP2:
  8,15
• Torque OP3:
  9,78
