General data

• Color:
  RAL7030
• Direction of rotation:
  right
• Duty type OP1:
  S1
• Housing type:
  L
• Insulation class utilization:
  B
• Motor design:
  Standard
• Motor type:
  Dual Capacitor
• Protection class (IP):
  IP55
• Terminal box orientation:
  Cable glands to non drive-end
• Technology:
  AC Asynchronous-Motor
• Frame size:
  90
• Mounting:
  B14a
• Material of housing:
  Aluminium

Electrical data

• Frequency OP1 (Hz):
  50
• Pole:
  4
• Power OP1 (kW):
  1,5
• Voltage OP1:
  230 V
• Efficiency class OP1:
  IE2
• Starting condensator (C):
  200 myF/300 V
• Operating condensator (C):
  40 myF/450 V

Mechanical data

• Ambient temperature:
  -20 up to +40 °C
• Bearing arrangement DE:
  loose
• Bearing arrangement NDE:
  loose
• Bearing drive-end:
  6205.ZZ.C3
• Bearing non drive-end:
  6205.ZZ.C3
• Cable glands:
  PG11
• Shaft dimension drive-end:
  24 x 50 mm
• Speed OP1 (1/min):
  1420
