General data

• Eff.Cl.50Hz:
  -
• Terminal box location:
  top DE
• Terminal box orientation:
  cable gland to the back side NDE
• Type designation:
  FBSP
• Mounting:
  B34a
• Frame size:
  71
• Frame material:
  AL
• Atex:
  -
• Duty:
  S1
• Frame execution:
  -
• Insulationclass:
  F/B
• Color:
  RAL7030
• Protection class:
  IP55

Electrical data

• Power 1 50Hz:
  0.55
• Poles:
  2
• Type of motor:
  1~
• Voltage 50Hz (V):
  230
• Voltage 60Hz (V):
  -
• Frequency (Hz):
  50
• Connection:
  -
• Capacitor:
  BK
• Rotation speed (1/min):
  2800

Mechanical data

• Ambient temperature (°C):
  -20 up to +40
• Bearing DE:
  6202.ZZ.C3
• Protection winding:
  -
• Cable gland size (cable connection):
  1xM16
• Cable gland size (option):
  -
• Mounting of bearing DE:
  loose bearing
• Mounting of bearing NDE:
  loose bearing
• Shaft end:
  14 x 30
