General data

• Eff.Cl.50Hz:
  IE4
• Terminal box location:
  top DE
• Terminal box orientation:
  cable gland to the right side
• Type designation:
  ACM
• Eff.Cl.60Hz:
  IE4
• Mounting:
  B14a
• Frame size:
  112
• Frame material:
  AL
• Atex:
  -
• Duty:
  S1
• Frame execution:
  M
• Insulationclass:
  F/B
• Color:
  RAL7030
• Protection class:
  IP55

Electrical data

• Power 1 50Hz:
  4
• Power 1 60Hz:
  4
• Poles:
  2
• Type of motor:
  3~
• Voltage 50Hz (V):
  230/400
• Voltage 60Hz (V):
  265/460
• Frequency (Hz):
  50/60
• Connection:
  Δ/Y
• Capacitor:
  -
• Rotation speed (1/min):
  2930/3516

Mechanical data

• Ambient temperature (°C):
  -20 up to +40
• Bearing DE:
  6306.ZZ.C3
• Protection winding:
  -
• Cable gland size (cable connection):
  1xM32x1,5 1xblind plug
• Cable gland size (option):
  -
• Mounting of bearing DE:
  loose bearing
• Mounting of bearing NDE:
  loose bearing
• Shaft end:
  28 x 60
