General data

  • Eff.Cl.50Hz:
    IE4
  • Terminal box location:
    top DE
  • Terminal box orientation:
    cable gland to the right side
  • Type designation:
    ACM
  • Eff.Cl.60Hz:
    IE4
  • Mounting:
    B3
  • Frame size:
    160
  • Frame material:
    Cast iron
  • Atex:
    -
  • Duty:
    S1
  • Frame execution:
    M
  • Insulationclass:
    F/B
  • Color:
    RAL7030
  • Protection class:
    IP55

Electrical data

  • Power 1 50Hz:
    11
  • Power 1 60Hz:
    11
  • Poles:
    2
  • Type of motor:
    3~
  • Voltage 50Hz (V):
    400/690
  • Voltage 60Hz (V):
    460/795
  • Frequency (Hz):
    50/60
  • Connection:
    Δ/Y
  • Capacitor:
    -
  • Rotation speed (1/min):
    2960/3552

Mechanical data

  • Ambient temperature (°C):
    -20 up to +40
  • Bearing DE:
    6209.ZZ.C3
  • Protection winding:
    PTC 150°C
  • Cable gland size (cable connection):
    1xM40x1,5 1xblind plug
  • Cable gland size (option):
    M20x1,5
  • Mounting of bearing DE:
    loose bearing
  • Mounting of bearing NDE:
    fixed bearing
  • Shaft end:
    42 x 110
All further technical data for this product can be found in the data sheet.
