General data

• Eff.Cl.50Hz:
  IE3
• Terminal box location:
  top DE
• Terminal box orientation:
  cable gland to the right side
• Type designation:
  AOA
• Eff.Cl.60Hz:
  IE3
• Mounting:
  B3
• Frame size:
  180
• Frame material:
  AL
• Atex:
  -
• Duty:
  S1
• Frame execution:
  M
• Insulationclass:
  F/B
• Color:
  RAL7030
• Protection class:
  IP55

Electrical data

• Power 1 50Hz:
  18.5
• Power 1 60Hz:
  18.5
• Poles:
  4
• Type of motor:
  3~
• Voltage 50Hz (V):
  400/690
• Voltage 60Hz (V):
  460/-
• Frequency (Hz):
  50/60
• Connection:
  Δ/Y
• Capacitor:
  -
• Rotation speed (1/min):
  1475/1770

Mechanical data

• Ambient temperature (°C):
  -20 up to +40
• Bearing DE:
  6310.ZZ.C3
• Protection winding:
  PTC 150°C
• Cable gland size (cable connection):
  2xM40x1,5
• Cable gland size (option):
  M20x1,5
• Mounting of bearing DE:
  loose bearing
• Mounting of bearing NDE:
  fixed bearing
• Shaft end:
  48 x 110
