General data

• Color:
  RAL7030
• Direction of rotation:
  right
• Duty type OP1:
  S1
• Insulation class utilization:
  B
• Motor design:
  Standard
• Motor type:
  Single Capacitor
• Protection class (IP):
  IP55
• Terminal box orientation:
  Cable glands to non drive-end
• Technology:
  AC Asynchronous-Motor
• Frame size:
  56
• Mounting:
  B3
• Material of housing:
  Aluminium

Electrical data

• Frequency OP1 (Hz):
  50
• Pole:
  2
• Power OP1 (kW):
  0,09
• Voltage OP1:
  230 V
• Operating condensator (C):
  4 myF/450 V

Mechanical data

• Ambient temperature:
  -20 up to +40 °C
• Bearing arrangement DE:
  loose
• Bearing arrangement NDE:
  loose
• Bearing drive-end:
  6201.ZZ.C3
• Bearing non drive-end:
  6201.ZZ.C3
• Cable glands:
  1xM16
• Shaft dimension drive-end:
  9 x 20 mm
• Speed OP1 (1/min):
  2800
