General data

• Balancing:
  Half key
• Color:
  RAL7030
• Direction of rotation:
  right
• Frame size:
  90
• Housing type:
  L
• Insulation class utilization:
  B
• Material of housing:
  Aluminium
• Motor type:
  Dual Capacitor
• Mounting:
  B14a

Electrical data

• Efficiency class OP1:
  IE2
• Frequency OP1:
  50
• Pole:
  4
• Power OP1:
  1,5
• Starting current factor OP1:
  5,5
• Starting torque factor OP1:
  2,5
• Voltage OP1:
  230 V

Mechanical data

• Speed OP1:
  1400
• Torque OP1:
  10,23
