General data

• Balancing:
  Half key
• Color:
  RAL7030
• Direction of rotation:
  left or right
• Frame size:
  112
• Housing type:
  M
• Insulation class utilization:
  B
• Material of housing:
  Aluminium
• Motor type:
  Regular
• Mounting:
  B5

Electrical data

• Efficiency class OP1:
  IE2
• Efficiency class OP2:
  IE2
• Frequency OP1:
  50
• Pole:
  4
• Power OP1:
  4
• Power OP2:
  4
• Starting current factor OP1:
  4,7
• Starting current factor OP2:
  4,7
• Starting torque factor OP1:
  2,3
• Starting torque factor OP2:
  2,3
• Starting torque factor OP3:
  2,3
• Voltage OP1:
  400/690 V
• Voltage OP2:
  460/795 V

Mechanical data

• Speed OP1:
  1440
• Speed OP2:
  1728
• Speed OP3:
  1728
• Torque OP1:
  26,53
• Torque OP2:
  22,11
• Torque OP3:
  26,53
